UNIVERSAL HEAVY DUTY KNEE TYPE MILLING MACHINE 2500UM

Capacity 2500UM
Table area 1500x350mm
Number of “T” shaped slots 5-16H7
Distance between “T” shaped slots 60mm
Rotary movement of table in both direction 45º
Automatic longitudinal 1150mm
Automatic cross 400mm
Automatic vertical 500mm
Available distance from spindle to overarm 155mm
Housing of the taper spindle ISO-40/50
Diameter of the main shaft nose 88.88-128.57mm
Milling arbor diameter 27mm
Number of speeds of the spindle 12(40-1800) 50HZ
Longitudinal and cross feeds 10-1208mm
Vertical feed 5-604mm
